产品概述
With the development of new-generation motor products, we offer customers a more diverse selection of high-quality hydraulic system components. The CMF fixed-displacement bent-axis motor features high load capacity and high speed. It utilizes standard interfaces, allowing for deployment across various application scenarios without additional components. Bent-axis motors improve cost-efficiency by reducing product weight and power losses.
产品优势
High speed.
High power density.
Very compact dimensions.
产品规格
|
Parameters |
Value |
|
Specification |
80 |
|
Max. displacement (cc/rev) |
80 |
|
Max. operating speed (100% duty cycle, max. displacement) (rpm) |
4500 |
|
Max. operating speed (intermittent, max. displacement) (rpm) |
5000 |
|
Rated pressure (bar) |
450 |
|
Max. pressure (instantaneous) (bar) |
500 |
|
Allowable case pressure (bar) |
2.5 |
|
Torque at rated pressure (N·m) |
547 |
|
Theoretical power (kW) |
258 |
|
Weight (approx.) (kg) |
23 |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
