High speed, low losses.
Suitable for road rollers, pavers, self-propelled modular transporters, loaders, horizontal directional drills, mobile cranes, rotary drilling rigs, crawler cranes, and oil fracturing trucks
额定压力 bar
最大排量 cc/rev
产品概述
With the development of new-generation motor products, we offer customers a more diverse selection of high-quality hydraulic system components. Bent-axis motors such as the CMV and CMF series feature standard interfaces, allowing them to be utilized in various application scenarios without the need for additional components. Bent-axis motors improve cost-efficiency by reducing product weight and power losses.
产品优势
High speed.
High power density.
Low losses.
产品规格
|
Parameters |
60 |
85 |
115 |
140 |
170 |
215 |
|
Max. displacement (cc/rev) |
62 |
87.7 |
115.3 |
144.1 |
170 |
217.9 |
|
Max. operating speed (100% duty cycle) at max. displacement (rpm) |
4450 |
3900 |
3550 |
3250 |
3100 |
2900 |
|
Max. operating speed (intermittent) at max. displacement (rpm) |
On-demand |
On-demand |
On-demand |
On-demand |
On-demand |
On-demand |
|
Max. operating speed (100% duty cycle) at min. displacement (rpm) |
7200 |
6800 |
6150 |
5600 |
4900 |
4600 |
|
Max. operating speed (intermittent) at min. displacement (rpm) |
On-demand |
On-demand |
On-demand |
On-demand |
On-demand |
On-demand |
|
Rated pressure (bar) |
450 |
450 |
450 |
450 |
450 |
450 |
|
Max. pressure (instantaneous) (bar) |
500 |
500 |
500 |
500 |
500 |
500 |
|
Allowable case pressure (bar) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
|
Torque (at rated pressure) (N·m) |
411 |
582 |
787 |
958 |
1163 |
1471 |
|
Power (theoretical power at max. continuous speed, max. displacement, and max. operating pressure) (kW) |
320 |
427 |
508 |
578 |
597 |
718 |
|
Weight (approx.) (kg) |
27.7 |
36.3 |
44.8 |
59.2 |
62.1 |
76.4 |
备注：产品参数及图片仅供参考；如有变动，不另行通知。
