WEICHAI

WPH2.5T-90-01 Range Extender for Tractors

90

额定功率(kW)

<2000

额定转速(rpm/min)

总成额定功率 kW

技术路线

产品概述

Weichais new generation oil-electric hybrid range-extender powertrain meets China VI emission standards, featuring a self-developed electric motor with a peak efficiency of 97%. Hybrid range-extender power significantly extends driving range, effectively resolving range anxiety for battery electric heavy-duty trucks; Triple integration of engine, motor, and motor controller ensures a compact size and high adaptability; Multiple iterations of noise reduction technologies significantly improve the NVH performance of the range extender.

产品优势

Higher Power Generation Efficiency: 5% higher efficiency compared to competitors, generating more electricity from the same amount of fuel for longer operating ranges.

Lighter Weight: Highly integrated engine, generator, and controller design results in a lighter powertrain assembly, allowing for higher cargo capacity and increased revenue for users.

Greater Reliability: Focuses on long-term stability and durability, ensuring consistent optimal performance under various operating environments and conditions; Minimize downtime and maintenance costs caused by failures, providing users with a more reassuring operational experience.

Quieter and more comfortable: Featuring synergistic combustion optimization, generator control adapted to vehicle duty cycles, and noise isolation measures, the noise level is reduced by over 3 dBA compared to competitors, delivering a quieter and more comfortable user experience.

产品规格

Assembly Rated power (kW) 90
Assembly Rated speed (rpm) <2000
Assembly Power generation efficiency (kW·h/L) >4.0
Engine Rated power (kW) 120
Engine Rated speed (rpm) 2900
Motor system Rated voltage (VDC) 666
Motor system Continuous/Peak power (kW) 130/150
Motor system Maximum efficiency 96%

备注:产品参数及图片仅供参考;如有变动,不另行通知。

型谱表

Model

Rated power generation (kW)

Target applications

WPH2.5T-90-01

90

Range-Extended 49t Tractor
